Alcatel Halo Series SIP DeskPhone

 Alcatel Halo Series SIP DeskPhone

The H3G Halo Series SIP DeskPhone is a budget-friendly and efficient communication solution designed for basic calling needs. With a 2.8-inch backlit black-and-white screen, it ensures clear visibility and smooth navigation. Its full-duplex audio allows for natural and uninterrupted conversations.

Equipped with two Gigabit Ethernet ports, this phone supports fast and stable connections. It also features low power consumption, multiple programmable keys, and external connection ports, making it an ideal choice for offices, call centers, and public service environments. Its easy deployment and high compatibility ensure a hassle-free setup.

CONDITION

Brand New - A brand-new, unused, unopened, undamaged item in its original packaging.

WARRANTY

This item comes with a 12-month manufacturer's warranty.

FEATURES

• Full duplex phones with 2.8” backlit B&W screen
• Selected components and CPU for robust performance
• Low power consumption
• More line/programmable keys and fast dial keys
• Ports for external connections
• Rich compatibility can realize easy deployment
• High capacity

QUICK SPECIFICATIONS

• Physical Characteristics:
• Dimensions (L x W x H): 214 mm x 191 mm x 47 mm
• Weight: 795 g (with handset and stand)
• Color: Gray
• H3P/H3G: 2.8-inch, 132 x 64 black and white display with backlight
• Adjustable stand: 45° & 50°
• Wall mountable (optional accessory)

• Keys:
• 3 LED line keys
• 4 menu keys (corresponding to display)
• Volume keys: (+ and -)
• 4-way navigation, return, and confirm keys
• 9 function keys: handsfree, mute, info, headset, hold, transfer, conference, redial, and hang up
• Standard dial pad

• Telephony Features:
• 3 SIP accounts
• Incoming/outgoing/rejected calls
• Call forwarding
• Call waiting
• Call hold/resume
• Redial
• Speed dial
• Mute/unmute
• Do not disturb (DND)
• Auto answer
• Voicemail
• Local 5-way conference
• Call Log: 1000 entries
• Contacts: 1000 entries

• Audio Characteristics:
• Full-duplex handsfree
• High-def broadband
• Codec: Opus (NB and WB), G.722, ILBC, G711 (a-law and u-law), G.729AB
• Voice Activity Detection (VAD)
• Comfort Noise Generation (CNG)
• Acoustic Echo Cancellation (AEC)
• DTMF: In-Band, RFC 2833/4733, SIP info
• Hearing Aid Compatible (HAC)

• Power:
• Power over Ethernet (IEEE 802.3af), Class 1
• Power adapter: 5V/2A DC output (optional)

• Connectivity:
• RJ-45 100M Ethernet Port (H3P)
• RJ-45 1000M Ethernet Port (H3G)
• RJ-9 handset connector
• RJ-9 headset connector

• Network, Security, and Other Protocols:
• SIP V2: RFC 2474, 2833, 3261, 3263, 3264, 3265, 3325, 3550, 4566, 4568, 5359, 6086, etc.
• Static IP and DHCP
• IPv4
• IEEE 802.1AB/LLDP-MED
• QoS: 802.1p/Q tagging (VLAN), Layer 3 TOS, DSCP
• TFTP/HTTP/HTTPS/TR069
• OPENVPN, 802.1x
• Authentication: basic or digest
• Denial-of-service (DoS) attack prevention
• TLS 1.2/1.0 and SRTP support
• Ships with X509v3 certificate, with support for client certificate installation

• Configuration:
• Web-based management, phone configuration, and automated configuration
• ALE Easy Provisioning Server (EPS)
• ALE Easy Deployment Server (EDS)
• Multi-language menu support: Simplified Chinese, Traditional Chinese, English, French, German, Italian, Korean, Portuguese, and Spanish

• Regulatory Standards:
• Security: IEC 62368-1:2014, ANSI/UL 62368-1-2014, CAN/CSA-C22.2 NO. 62368-1-14
• EMC: EN 55032, CISPR 32, EN 55024, CISPR 24, EN 61000-3-2, EN 61000-3-3, 47 CFR Part 15 B Subpart B, ICES-003 Issue 6
• Telecommunications Standards: TIA/EIA 810-B, TIA 920.130-A-1, AS/CA S004
• Eco Design: ErP 2009/125/EC, WEEE 2012/19/EU, ROHS 2011/65/EU, China RoHS 2.0: GBT 26572-2011, REACH (EC1907/2006), Proposition 65, Packaging: EU 94/62/EC

• Hearing Aid Compatibility:
• FCC 47 CFR Part 68, CS-03, AS/ACIF S040

• Environmental Conditions:
• Operating temperature: -5°C to +45°C
• Relative humidity: 5% to 95%
• Storage/transportation temperature: -25°C/+70°C

WHAT'S INCLUDED

• H3G DeskPhone
• Wired HD wideband handset and cable
• Phone stand
• 1.5 m network cable (cat5e)
• User Guide

IMPORTANT

This is an IP Telephone. It requires an IP account from your provider. Your IP provider will be able to provide credentials to load into your phone. If your provider requires certain firmware to use this phone on their network please contact us before purchasing
